Cisco Catalyst WS-C3650-48TD-L Switch
EGP6,700.00
- Number of Ports : 48 x 10/100/1000 Mbps Ethernet PoE+ ports , 2 x 10G SFP+ ports
- Power Over Ethernet (PoE):PoE+
- Layer : Layer 3
- Managed : yes
- Condition : Used
- Warranty: 6 months
1 in stock
The Cisco Catalyst 3650 Series is a line of enterprise-class switches, strategically designed to deliver a unified wired and wireless network experience. Built upon the Cisco Unified Access™ Data Plane (UADP) application-specific integrated circuit (ASIC), these switches not only offer uniform wired-wireless policy enforcement, but also provide enhanced application visibility, operational flexibility, and superior resiliency. Consequently, they are well-suited for organizations aiming to streamline network operations while maintaining performance and security across both access types.
For more details, you can find the datasheet on our website at the following link :
Cisco Catalyst 3650 Series Switches Data Sheet
The Cisco Catalyst WS-C3650-48TD-
Key Features:
- Unified Wired and Wireless Access: Built on the advanced Cisco StackWise-160 technology, the Catalyst 3650 series facilitates full convergence between wired and wireless networks on a single platform, simplifying network management and enhancing user experiences.
- High PoE+ Power Budget: The WS-C3650-48FQ-L model provides a substantial PoE+ power budget, delivering up to 775W. This enables the support of high-power devices such as IP phones, wireless access points, and surveillance cameras without the need for separate power sources.
- Advanced Security Features: Equipped with comprehensive security capabilities, the Catalyst 3650 series includes features like IEEE 802.1X authentication, Dynamic ARP Inspection, and IP Source Guard, ensuring robust protection against unauthorized access and network threats.
- Scalability with StackWise-160: The Catalyst 3650 series supports Cisco StackWise-160 technology, allowing for the stacking of up to 9 switches with a total stack bandwidth of 160 Gbps. This scalability ensures that the network can grow with organizational needs while maintaining high performance.
- Comprehensive Management Options: Managed via Cisco IOS XE software, the Catalyst 3650 series offers a consistent command-line interface (CLI) and supports various management protocols, including SNMP, RMON, Telnet, and SSH, providing flexibility and ease of network management.
- High Switching Capacity and Forwarding Rate: Designed to handle demanding network traffic, the Catalyst 3650 series offers a switching capacity of up to 176 Gbps and a forwarding rate of 130.95 million packets per second, ensuring efficient data transmission and reduced latency
| Brand | Cisco |
|---|---|
| Model | WS-C3650-48TD-L |
| Product Type | Managed Layer 3 Network Switch |
| Series | Catalyst 3650 Series |
| Power Over Ethernet (PoE) | Supports PoE+ with a total power budget of 640W, delivering up to 30W per port |
| LAN Ports | 48 x 10/100/1000 Mbps Ethernet PoE+ ports |
| Fiber Uplink Ports | 2 x 10G SFP+ uplink ports |
| Layer Support | Layer 3 |
| Dimensions (H x W x D) | 1.75 x 17.5 x 17.6 inches |
| Weight | Approximately 16.01 lbs (7.26 kg) |
| Rack Units (RU) | 1U |
| Default Power Supply | 640W AC power supply |
| Operating Temperature | 23°F to 113°F (-5°C to 45°C) |
| Input Voltage | 100 to 240 VAC, 50-60 Hz |
| Console Cable | Includes USB mini-Type B console port and RJ-45 console port |
| Media Type Supported | Twisted pair and fiber optic |
| Processor & Memory | 4 GB RAM and 2 GB flash memory |
| Fan | Redundant fans |
| Switching Capacity | 160 Gbps |
| Forwarding Rate | 130.95 Mpps |
| MAC Address Table Size | 32K entries |
| Stacking | Supports stacking up to 9 switches with StackWise-160 technology, providing 160 Gbps stack bandwidth |
