Lenovo ThinkAgile HX5520 12×3.5″
The Lenovo ThinkAgile HX5520 Appliance (Xeon SP Gen 1), a withdrawn 2U rack-mount hyperconverged solution, simplifies IT infrastructure and reduces costs for storage-heavy workloads like file servers and big data. Powered by Nutanix software and Lenovo ThinkSystem servers, it features two Intel Xeon Gen 1 processors, up to 3 TB TruDDR4 memory, 12 or 14 SAS/SATA drive bays, and flexible 1/10/25 GbE connectivity. Additionally, its pre-configured design ensures easy deployment.
Features
- Fault-Resistant Architecture: Nutanix’s shared-nothing design distributes data, metadata, and services across cluster nodes, eliminating single points of failure.
- Data Protection: Provides VM-granular data protection with customizable recovery point objectives (RPO) and recovery time objectives (RTO).
- Intuitive Management: Nutanix Prism delivers a user-centric interface for simplified monitoring, automation, and workflows.
- Advanced Systems Management: Lenovo XClarity Controller (XCC) Enterprise supports proactive alerts, light path diagnostics, and optional XClarity Energy Manager.
- Flexible Connectivity: Offers up to eight 1/10 GbE RJ-45, 10 GbE SFP+, or 25 GbE SFP28 ports for robust network performance.
- I/O Scalability: Supports up to six PCIe 3.0 slots (12-drive bay models) or four slots (14-drive bay models) for expansion.
- ThinkAgile Advantage Support: Provides 24/7 single-point-of-contact support with three-, four-, or five-year warranty and software maintenance options.
Security
- Password Protection: Features power-on and administrator passwords to secure system access.
- Secure Firmware Updates: Ensures system integrity through protected firmware update processes.
- Trusted Platform Module (TPM): Supports TPM 1.2 or 2.0 with configurable UEFI settings for enhanced security.
- Nutanix Software Security: Includes two-factor authentication and data-at-rest encryption, backed by a security development lifecycle integrated into product design.
- Optional Security Bezel: Provides physical access protection to prevent unauthorized tampering.
For more details, you can view the data sheet on our website using the following link: Technical Guide
| Form factor | 2U |
|---|---|
| Processor | Two Intel Xeon Silver, Gold, or Platinum Gen 1 processors. |
| No. Of processor socket | 2 |
| Support graphic card | Matrox G200 with 16 MB memory integrated into the XClarity Controller. Maximum resolution is |
| Ram type | DDR4 |
| Total Memory slots | 24 DIMM slots |
| Supported ram | 4 GB, 8 GB, 16 GB, 32 GB, 64 GB |
| Max memory | Up to 3 TB DDR4 2666 MHz |
| PCle slots | -6x PCIe 3.0 slots |
| Support Raid controller | 1x 430-16i HBA (12 Gbps SAS/6 Gbps SATA) |
| Support hard drive | 12×3.5-inch SAS/SATA hot-swap. |
| Network controller | -2x or 4x base 1/10 GbE RJ-45 or 10 GbE SFP+ network ports. |
| I/O Port | Front: 1x USB 2.0 port with XClarity Controller access, 1x USB 3.0 port, 1x VGA port. |
| Power supply | Two redundant hot-swap : |
| Remote management | XClarity Controller (XCC) Enterprise (Pilot 4 chip), proactive platform alerts, light path diagnostics, |
| Operating system | Nutanix Acropolis Hypervisor (Bundled with AOS). |
| Dimensions | Height: 87 mm (3.4 in) |
| Weight | Max : 32 kg (70.5 lb) |
| Operation temperature | 10°C to 35°C (50°F to 95°F) |
| Condition | Used |
| Warranty | 1 year |
