Qnap VIOSTOR 6120 PRO+ 6×3.5″

The QNAP VioStor VS-6120 Pro+ is a 20-channel network video recorder (NVR), designed for small to medium-sized businesses or professional surveillance systems. It offers an all-in-one solution for managing video surveillance, providing local storage and remote backup capabilities. With 6 internal hard drive bays, it can accommodate up to 24TB of storage (using 4TB drives), allowing ample space for high-resolution footage.

Security:

• HTTPS (SSL Encryption): Ensures secure web access to the management interface.

• User Authentication & RBAC: Role-based access control allows you to assign specific roles (admin, viewer, operator) for different users, integrating with LDAP for centralized authentication.

• IP Camera Security: ONVIF compatibility ensures only authorized cameras connect, with secure camera streaming to prevent tampering.

• Network Security: Features like firewall settings, 802.1X network authentication, and VPN support help protect against unauthorized access.

• Data Encryption: Protects footage with RAID configurations (0, 1, 5, 6), encrypted backups, and secure data transfer via RSYNC and iSCSI.

• Audit Logs & Event Notifications: Monitors all access and system events, sending email/SMS alerts for critical issues like unauthorized access or drive failures.

• Two-Factor Authentication (2FA): Adds an extra layer of protection for logging into the management interface.

Features:

• Dual-Core Intel Processor: Handles smooth video recording, playback, and management of 20 camera feeds simultaneously.

• Hot-Swappable HDD Bays: Easily replace or upgrade storage without system downtime.

• RAID Support: Includes RAID 0, 1, 5, 6, JBOD for data protection and optimization.

• Dual Gigabit Ethernet: Provides network reliability with failover and load balancing.

• USB Ports: Includes both USB 3.0 and USB 2.0 for external devices and backup.

• HDMI & VGA Outputs: Connect to monitors for live video and management.

• Mobile Access: Access video feeds and playback remotely using the QNAP VMobile app (iOS/Android).

• ONVIF Compatibility: Ensures easy integration with a wide range of IP cameras.

For more details, you can view the data sheet on our website using the following link: Spec sheet
